GC5020 & GC5030 Series Contemporary Luminaires

FEATURES

• Stylish and efficient contemporary lighting fixtures for post top mounting

• Lightweight cast aluminum fixture base with set screws for installation

• Slip fits over common 4” OD tenons on most decorative poles

• Durable Powder Coat Finish

• 0-10v Dimming Capability

• ETL Listed

LED LIGHT SOURCE OPTIONS

• 3 Power Levels

• 4 Color Temperatures

• 4 Light Distributions
  (HID Version Available-Consult Factory)

MATERIALS

• Fitter - Cast Aluminum (A356)

• Struts - Extruded Aluminum

• Shades - Spun Aluminum

• Lens (opt) - Acrylic

• Hardware - Stainless Steel

LENS OPTION

• NL - No Lens (Highest LPW)

• CA - Clear Acrylic

ACCESSORIES

• Photocell

• House Side Shield

• Surge Protection 10kV/10kA

LED MODULES AVAILABLE

G2 Series (used in conjunction with -NL Lens option)

• 12 High efficacy multi-die packages

• 2x6 LED Configuration

• 80CRI - 2700, 3000, 4000, 5000 CCT

G3 Series (used in conjunction with -CA Lens Option)

• 16 High efficacy multi-die packages

• (4) 2x2 LED Configurations

• 70CRI - 2700, 3000, 4000, 5000 CCT

LED OPTICS

• 2x6 Multi Lens or 2x2 Multi Lens

• PMMA (Acrylic)

• IES Type II, III, IV, V

• Silicone Gasket (2x6 Multi Lens)

• IP66 System (2x6 Multi Lens)

DOWNLOADS

• GC5020 & GC5030-CA (Clear Acrylic Lens) Series Spec Sheet

• GC5020 & GC5030-NL (No Lens) Series Spec Sheet
